Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
Audio Serial Triggering and A nalysis Module. Enables triggering on packet-level information on I2S, LJ,
RJ, and TDM audio buses as well as analytical tools such as digital views of the signal, bus views, packet
decoding, sea
rch tools, and packet decode tables with time-stamp information.
DPO4AUDIO,
MDO3AUDIO
BUS:B<x>:AU
Dio:BITDelay
BUS:B<x>:AUDio:BITOrder
BUS:B<x>:AUDio:CHANnel:SIZe
BUS:B<x>:A
UDio:CLOCk:POLarity
BUS:B<x>:AUDio:CLOCk:SOUrce
BUS:B<x>:AUDio:DATa:POLarity
BUS:B<x>:
AUDio:DATa:SIZe
BUS:B<x>:AUDio:DATa:SOUrce
BUS:B<x>:AUDio:DISplay:FORMat
BUS:B<x>
:AUDio:FRAME:SIZe
BUS:B<x>:AUDio:FRAMESync:POLarity
BUS:B<x>:AUDio:FRAMESync:SOUrce
BUS:B<x>
:AUDio:TYPe
BUS:B<x>:AUDio:WORDSel:POLarity
BUS:B<x>:AUDio:WORDSel:SOUrce
SEARCH:
SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:CONDition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:OFFSet
SEARCH
:SEARCH<x>:TRIGger:A:BUS :B<x>:AU D io:DATa:QUALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:VALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AUDio:DATa:WORD
TRIGg
er:A:BUS:B<x>:AUDio:CONDition
TRIGger:A:BUS:B<x>:AUDio:DATa:HIVALue
TRIGger:A:BUS:B<x>:AUDio:DATa:OFFSet
TRIGg
er:A:BUS:B<x>:AUDio:DATa:QUALifier
TRIGger:A:BUS:B<x>:AUDio:DATa:VALue
TRIGger:A:BUS:B<x>:AUDio:DATa:WORD
Aut
omotive Serial Triggering and Analysis Module. Enables triggering on packet-level information on CAN,
CAN FD, and LIN buses as well as analytical tools such as digital views of the signal, bus views, packet
decoding, search tools, and packet decode tables with time-stamp information.
DPO
4AUTO,
MDO3AUTO
BUS:B<x>:CAN:BITRate
BU
S:B<x>:CAN:FD:BITRate
BUS:B<x>:CAN:FD:STANDard
BUS:B<x>:CAN:PRObe
BU
S:B<x>:CAN:SAMPLEpoint
BUS:B<x>:CAN:SOUrce
BUS:B<x>:CAN:STANDard
G-4 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
