Tektronix MDO3000 Series Program Manual

Command Groups
Table 2-42: Vertical Commands (cont.)
Command Description
CH<x>:PRObe:CALibrate:STATE? This query returns the calibration state of the probe connected to the specified
channel.
CH<x>:PRObe:COMMAND Sets the state of the specified probe control
CH<x>:PRObe:DEGAUss Starts a degauss/autozero cycle on a TekVPI current probe attached to the
specified channel input
CH<x>:PRObe:DEGAUss:STATE? Returns the state of the probe degauss
CH<x>:PRObe:FORCEDRange This command specifies the range on a TekVPI probe attached to the specified
channel
CH<x>:PRObe:GAIN This command specifies the gain factor of the probe that is attached to the
specified channel
CH<x>:PRObe:ID? Returns the type and serial number of the probe that is attached to the
specified channel
CH<x>:PRObe:ID:SERnumber? Returns the serial number of the probe that is attached to the specified channel
CH<x>:PRObe:ID:TYPe? Returns the type of probe that is attached to the specifi ed channel
CH<x>:PRObe:MODel This command specifi es the probe model for the specified channel
CH<x>:PRObe:PROPDELay This command specifies the propagation delay for the probe connected to
the specified channel
CH<x>:PRObe:RECDESkew? Returns the recommended deskew for the probe connected to the specified
channel
CH<x>:PRObe:RESistance? Returns the resistance of the probe that is attached to the specified channel
CH<x>:PRObe:SIGnal This command specifies the input bypass setting of channel <x>TekVPI probe
CH<x>:PRObe:UN Its? Returns the units of measure of the probe that is attached to the specified
channel
CH<x>:SCAle This command specifi es the vertical scale of the specified channel
CH<x>:TERmination This command specifies channel input termination
CH<x>:YUNits This command specifies the units for the specified channel
D<x>
Returns parameters for digital c hannel <x>
D<x>:LABel
This command specifies the waveform label for digital channel<x>
D<x>:THReshold
This command specifies the logical threshold for the digital channel <x>, where
x is the digital channel number D0 – D 15.
D<x>:POSition This command specifies the vertical position for digital channel <x>
DESkew Causes the deskew values for all channels to be set to the recommended
values
DESkew:DISPlay Specifies the state of the deskew table display.
DISplay:INTENSITy:BACKLight:AUTODim:TIMe This command specifies the state of the deskew table display
REF<x>? Returns reference waveform data for channel <x>
REF<x>:DATE? Returns the date that a reference waveform was stored
REF<x>:HORizontal:DELay:TIMe This command specifies the horizontal position of the specified reference
waveform in percent of the waveform that is displayed to the right o f the center
vertical graticule
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-93
