Tektronix MDO4000B Series

Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
MDO4TRIG
Advanced RF Po
wer Level Triggering Module. E nables the power level on the RF input to be used as a
source in the following trigger types: Pulse Width, Runt, Timeout, Logic, and Sequence.
TRIGger:A:LOGIc:CLAss *
TRIGger:A:LOGIc:INPut:CLOC k:SOUrce *
TRIGger:A:L
OGIc:INPut:RF
TRIGger:A:LOGIc:THReshold:RF
TRIGger:A:LOWerthreshold:RF
TRIGger:A:
PULSEWidth:SOUrce*
TRIGger:A:RUNT:SOUrce*
TRIGger:A:TIMEOut:SOUrce*
TRIGger:A
:UPPerthreshold:RF
TRIGger:B:EDGE:SOUrce*
* The application m odule enables the RF argument for this command.
G-20 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
