Tektronix MDO4000B Series

Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
DPO4USB,
MDO3USB
TRIGger:A:BUS:B<x>:USB:QUALifier
TRIGger:A:BUS:B<x>:USB:SOFFRAMENUMber
TRIGger:A:B
US:B<x>:USB:SPECIALType
TRIGger:A:BUS:B<x>:USB:SPLit:ET:VALue
TRIGger:A:BUS:B<x>:USB:SPLit:HUB:VALue
TRIGger:A:
BUS:B<x>:USB:SPLit:PORT:VALue
TRIGger:A:BUS:B<x>:USB:SPLit:SC:VALue
TRIGger:A:BUS:B<x>:USB:SPLit:SE:VALue
TRIGger:A:
BUS:B<x>:USB:TOKENType
DPO4VID HDTV and Custom (nonstandard) Video Triggering Module. Not necessary for MDO3000 series as these
features come standard.
TRIGger:A:VIDeo:CUSTom{:FORMat|:TYPe}
TRIGger:
A:VIDeo:CUSTom:LINEPeriod
TRIGger:A:VIDeo:CUSTom:SYNCInterval
TRIGger:A:VIDeo:STANdard (The application module enables the arguments for HDTV and custom
(nonsta
ndard) to be used with this command.)
VIDPic:AUTOContrast
VIDPic:AUTOContrast:UPDATERate
VIDPic
:BRIGHTNess
VIDPic:CONTRast
VIDPic:DISplay
VIDPic
:FRAMETYP e
VIDPic:LOCation:HEIght
VIDPic:LOCation:OFFSet
VIDPi
c:LOCation:STARt:LINE
VIDPic:LOCation:STARt:PIXel
VIDPic:LOCation:WIDth
VIDP
ic:LOCation:X
VIDPic:LOCation:Y
VIDPic:SOUrce
VID
Pic:STANdard
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual G-19
