Tektronix MDO4000B Series User Manual

Command Groups
Table 2-31: Mask commands (cont.)
Command
Description
MASK:USER:TRIGTOSAMP Specifies the nominal time, in seconds, from the (leading edge) trigger position to the pulse
bit sampling position, to be used for testing with a u ser-defined custom mask.
MASK:USER:VOFFSet Specifies the nominal value, in volts, to be used to vertically offset the input channels
for a user-defi ned custom m a sk.
MASK:USER:VPOS Specifies the nominal value, in divisions, to be used to vertically position the input channels
for a user-defi ned custom m a sk.
MASK:USER:VSCAle Specifies the nominal value, in volts per division, to be used to vertically scale the input
channels for a user-defined custom mask.
MASK:USER:WIDth Specifies the nominal bit width value, in seconds, to be used for a user-defined custom
mask.
RECAll:MASK This command recalls the mask from a specified file that was saved to the current working
directory using the SAVe:MASK command.
SAVe:MASK This command saves the current mask defi nition to the file specified with a quoted string,
into the current working directory. You can recall the mask from the file by using the
command RECAll:MASK.
2-34 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
