Commands Listed in Alphabetical Order
NOTE.
Use the
TRIGger:A:BUS :B<x>:MIL1553B:CONDition:STATus:BIT
commands to se
t the following bits:
9 — me ssage error
TRIGger:A:
BUS:B<x>:MIL1553B:STATus:BIT:ME
10 — instrumentation
TRIGger:A:
BUS:B<x>:MIL1553B:STATus:BIT:INSTR
11 — SRQ (service request)
TRIGger:A
:BUS:B<x>:MIL1553B:STATus:BIT:SRQ
15 — BCR (broadcast command received)
TRIGger:
A:BUS:B<x>:MIL1553B:STATus:BIT:BCR
16 — busy
TRIGger
:A:BUS:B<x>:MIL1553B:STATus:BIT:BUSY
17 — subsystem flag
TRIGge
r:A:BUS:B<x>:MIL1553B:STATus:BIT:SUBSF
18 — DBCA (dynamic b us control acceptance)
TRIGg
er:A:BUS:B<x>:MIL1553B:STATus:BIT:DBCA
19 — terminal flag
TRIG
ger:A:BUS:B<x>:MIL1553B:STATus:BIT:TF
Examples
:TRIGger:A:BUS:B1:MIL1553B:CONDition STATus sets the word type to
trigger on to
STATus.
:TRIGger:A:BUS:B1:MIL1553B:CONDition? might return DATA.
TRIGger:A:BUS:B<x>:MIL1553B:DATa:PARity
When the MIL-STD-1553 bus trigger condition is set to DATa, this command
specifies the data parity bit to be used in the trigger. Returned values are 0,1,or
X (don’t care).
B<x>
Conditions
This command requires a DPO4AERO application module for DPO/MSO4000B
and MDO4000/B/C models or MDO3AERO application module for
MDO3000 models.
Group
Trigger
2-838 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
