Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARC H<x>:T RIG ger:A:BUS:B<x>:I2C:DATa:SIZe This command specifies the length of the data string in bytes to
be used for I2C search
SEARCH:SEARC H<x>:T RIG ger:A:BUS:B<x>:I2C:DATa:
VALue
This command specifiesthebinarydatastringtobeusedforI2C
search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:LIN:COND ition This command specifies the search condition for a LIN search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:LIN:DATa:
HIVALue
This command specifies the binary data string
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:LIN:DATa:
QUALifier
This command specifies the L IN data qualifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:LIN:DATa:SIZe This command specifies the length of the data string in bytes
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:LIN:DATa:
VALue
This command specifies the binary data string used for a LIN search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:LIN:ERRTYPE This command specifies the error type used for a LIN search
SEARCH:SEARC H<x>:T RIG ger:A:BUS:B<x>:LIN:IDenti fier:
VALue
This command specifi es the binary address string used for LIN
search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:ADDRess:HIVALue
When the MIL-STD-1553 bus search condition is set to COMMAND,
and the qualifier is set to
INrange or OUTrange, this command
specifies the upper limit of the range for the remote terminal
address field.
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:MIL1553B:
COMMAND:ADDR:QUAL
When the MIL-STD-1553 bus search condition is set to COMMAND,
this command specifies the qualifier to be used with the remote
terminal address field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:ADDRess:VALue
When the MIL-STD-1553 bus search condition is set to COMMAND,
and the qualifier is set to
LESSthan, MOREthan, EQual,
UNEQual, LESSEQual
or MOREEQual, this command
specifies the value of the 5–bit remote terminal address to be used
in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:COUNt
When the MIL-STD-1553 bus search condition is set to COMMAND,
this command speci fies the bit pattern for the 5–bit Word
Count/Mode Code sub-address field that is to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:PARity
When the MIL-STD-1553 bus search condition is set to COMMAND,
this command specifies the Command word parity that is to be used
in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:SUBADdress
When the MIL-STD-1553 bus search condition is set to COMMAND,
this command specifies the 5 bit sub-address that is to be used
in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
COMMAND:TRBit
When the MIL-STD-1553 bus search condition is set to COMMAND,
this command specifies that the transmit/receive bit (bit 9 ) is to be
used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
CONDition
This command specifies a word type or condition within a
MIL-STD-1553 bus word to search for.
SEARCH<x> is the search
number, w hich is always 1, and
B<x>
