Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
DATa:PARity
When the MIL-STD-1553 bus search condition is set to DATa,this
command specifies the data parity bit to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
DATa:VALue
When the MIL-STD-1553 bus search condition is set to DATa,this
command specifies the data binary pattern to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
ERRTYPE
When the MIL-STD-1553 bus search condition is set to ERRor,
this command specifies the signaling error type to be used in the
search: Parity, Sync, Manchester or Data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:ADDRess:HIVALue
When the M IL-STD-1553 bus search condition is set to STATus,
and the qualifier is set to
INrange or OUTrange, this command
specifies the upper limit for the 5 bit remote terminal address field
of the Status word.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:ADDRess:VALue
When the M IL-STD-1553 bus search condition is set to STATus,
and the qualifier is set to
LESSthan, MOREthan, EQual,
UNEQual, LESSEQual
or MOREEQual, this command
specifies the value of the 5–bit remote terminal address to be used
in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:ADDRess:QUALifier
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the qualifier to be used with the address
field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:BIT:BCR
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the s tatus word broadcast command
received (BCR) bit value (bit 15) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:BIT:BUSY
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the status word busy bit value ( bit 16) to be
used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:BIT:DBCA
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the s tatus word dynamic bus control
acceptance (DBCA) bit value (bit 18) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus :BIT:INSTR
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the status w ord instrumentation bit value
(bit 10) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus :BIT:ME
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the status word message error bit value
(bit 9) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:BIT:SRQ
When the M IL-STD-1553 bus search condition is set to STATus,
this command speci fies the status w ord service request (SRQ) bit
value (bit 11) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus:BIT:SUBSF
When the M IL-STD-1553 bus search condition is set to STATus,
this command specifies the status w ord subsystem flag bit value
(bit 17) to be used in the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:MIL1553B:
STATus :BIT:TF
When theMIL-STD-1553 bus search condition is set to STATus,
this command specifies the status word terminal flag bit value (bit
19) to be used in the search.
2-68 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
