Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
STATus:PARity
When the MIL-STD-1553 bus search condition is set to STATus,
this command species the status parity bit value to be used in
the search.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
TIMe:LESSLimit
When the MIL-STD-1553 bus search condition is set to TI Me ,this
command species either the minimum remote terminal response
time (RT) limit for the amount of time the terminal has to transmit, or
it speci es the minimum inter-message gap (IMG).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
TIMe:MORELimit
When the MIL-STD-1553 bus search condition is set to TI Me ,this
command species either the maximum remote terminal response
time (RT) limit for the amount of time the terminal has to transmit, or
it speci es the maximum inter-message gap (IMG).
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:MIL1553B :
TIMe:QUALier
When the MIL-STD-1553 bus search condition is set to TIMe,this
command species the trigger data time qualier.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:PARallel:
VALue
This command speci esthebinarydatastringtobeusedfora
Parallel search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:RS232C:
CONDition
This command species the search condition for an RS-232 trigger
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:RS232C:RX:
DATa:SIZe
This command species the length o f the data string for an
RS-232search, if the search condition is RX
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:RS232C:RX:
DATa:VALue
This command species the binary data string for an RS-232 search,
if the condition involves RX
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:RS232C:TX:
DATa:SIZe
This command species the length of the data string to be used for
an RS-232 search, if the search condition is TX
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:RS232C:TX:
DATa:VALue
This command species the binary data string to be used for an
RS-232 search, if the condition involves RX
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:SPI:CONDition This command species the search condition for SPI search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:SPI:DATa{:
MISO|:IN}:VALue
This command species the binary data string to be used for SPI
search if the search condition is MISO or MISOMOSI
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:SPI:DATa{:
MOSI|:OUT}:VALue
This command species the binary data string for an SPI search if
the search condition is MISO or MISOMOSI
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:SPI:DATa:SIZe This command species the length of the data string in bytes to
be used for SPI search
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:USB :
ADDRess:HIVALue
This command species the high limit for USB address searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:USB :
ADDRess:VALue
This command species the value for USB address searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:USB :
CONDition
This command species the USB search condition.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:USB :DATa:
HIVALue
This command species the high limit for USB data searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B <x>:USB :DATa:
OFFSet
This command species the data offset for USB data searches
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-69
