Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:DATa:
SIZe
This command specifies the number of data bytes for US B searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:DATa:
TYPe
This command specifies the data type for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:DATa:
VALue
This command specifies the data value for USB data searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
ENDPoint:VALue
This command specifies the endpoint value for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
ERRTYPE
This command specifies the error type for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
HANDSHAKEType
This command specifies the handshake type for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:USB:QU ALifier This command specifies the qualifier for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
SOFFRAME NU M ber
This command specifies the SOF number for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
SPECIALType
This command specifies the special packet type for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:SPLit:E T:
VALue
When searching on a high-speed USB split transaction, this
command specifies the split transaction endpoint type value to
search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:SPLit:
HUB:VALue
When searching on a high-speed USB split transaction, this
command specifies the split transaction hub address value to
search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:SPLit:
PORT:VALue
When searching on a high-speed USB split transaction, this
command specifies the split transaction port address value to
search for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:SPLit:SC:
VALue
When searching on a high-speed USB split transaction, this
command specifies whether to search for the start or complete
phase of the split transaction, based on the Start/Complete bit field
value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:SPLit:S E:
VALue
When searching for a high-speed USB split transaction, this
command specifies the split transaction start/end bit value to search
for.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:US B:
TOKENType
This command specifies the token type for USB searches
SEARCH:SEARCH<x>:TRIGger:A:BUS:SOU rc e This command specifies the bus for a serial search
SEARCH:SEARCH<x>:TRIGger:A:EDGE:SLOpe This command specifies the slope to be used in an edge search:
rising, falling or either
SEARCH:SEARCH<x>:TRIGger:A:EDGE:SOUrce This command specifies the source waveform for an edge search
SEARCH:SEARCH<x>:TRIGger:A:LEVel:CH<x>
Sets the threshold level to use when searching on an analog
waveform.
2-70 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
