Command Groups
Table 2-39: Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:LEVel:MATH
Sets the threshold level to use when searching on the math
waveform.
SEARCH:SEARCH<x>:TRIGger:A:LEVel:REF<x>
Sets the threshold level to use when searching on a reference
waveform.
SEARCH:SEARCH<x>:TRIGger:A:LEVel:RF_AMPlitude
Sets the threshold level to use when searching on the RF Amplitude
vs. Time trace.
SEARCH:SEARCH<x>:TRIGger:A:LEVel:RF_FREQuency
Sets the threshold level to use when searching on the RF Frequency
vs. Time trace.
SEARCH:SEARCH<x>:TRIGger:A:LEVel:RF_PHASe
Sets the threshold level to use when searching on the RF Phase
vs. Time trace.
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:FU NCtion Specifies the logic operator to be used in a logic search.
SEARCH:SEARC H<x>:T RIG ger:A:LO G Ic:PATtern:INPut:
CH<x>
This command specifies the logic operator for the logic search
SEARCH:SEARC H<x>:TRIGger:A:LOGIc:INPut:CH <x> Specifies the logic condition to be used in a logic s earch when the
input is an analog channel.
SEARCH:SEARC H<x>:TRIGger:A:LOGIc:INPut:CLOC k:
EDGE
This command specifies whether the clock edge is rise or fall for
a logic search
SEARCH:SEARC H<x>:TRIGger:A:LOGIc:INPut:CLOC k:
SOUrce
This command specifies the clock source de finition for logic search
SEARCH:SEARC H<x>:TRIGger:A:LOGIc:INPut:D<x> This command specifies the criteria for a logic search to determine
where to place a mark for digital channel <x>
SEARCH:SEARC H<x>:T RIG ger:A:LO G Ic:IN Put:M ATH This command specifies the Boolean logic criteria for the logic
search
SEARCH:SEARC H<x>:T RIG ger:A:LOGIc:INPut:REF<x> This command specifies the Boolean logic criteria for the logic
search
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:INPut:
RF_AMPlitude
This command specifies the logic criteria to search for when
searching using the RF Amplitude vs. Time trace. This command
is used together with SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:RF_AMPlitude to search for an instance when the
waveform goes higher or lower than the specified threshold.
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:INPut:
RF_FREQuency
This command specifies the logic criteria to search for when
searching using the RF Frequency vs. Time trace. This command
is used together with SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:RF_FREQuency to search for an instance when the
waveform goes higher or lower than the specified threshold.
SEARCH:SEARC H<x>:TRIGger:A:LOGIc:INPut:RF_P HAS e This command specifies the logic criteria to search for when
searching using the RF Phase vs. Time trace. This command
is used together with SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:RF_PHASe to search for an instance when the
waveform goes higher or lower than the specified threshold.
SEARCH:SEARC H<x>:T RIG ger:A:LO G Ic:PATtern:WHEn This command specifies the condition for generating a logic pattern
search.
