SPG600 & SPG300 Sync Pulse G enerators Quick Reference Manual
Genlock Menu
Pressing the GENLOC K button displays the Genlock menu. This menu lets you
select the genlock source, set the timing offset, and set the instrument actions
when lock is lost. Use the up (
Y)ordown(B) arrow button to scroll through the
menu. Figure 18 shows the Genlock menu diagram.
GENLOCK STATUS
Internal
Press the GEN
OCK button
GENLOCK SOURCE
H Internal ↵
Internal CW 1 MHz
525 SYNC CW 3.58 MHz
NTSC Burst CW 4.43 MHz
625 SYNC CW 5 MHz
PAL Burst CW 10 MHz
GENLOCK TIMING
To Genlock timing submenu
(page 19)
ENTER
CANCEL
LOCK LOSS ACTION
H Internal Mode ↵
Internal Mode
Stay Mode
Figure 18: Genlock menu diagram
