Command Descriptions

2-48

TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer

NOTE. Any change made when i n Ave rage mode aborts the

acquisition and resets ACQuire:NUMACq to zero.

H TDS200: changing the vertical position does not reset the value

H TDS1000, TDS2000, TDS1000B, TDS2000B, and TPS2000

series: if the Trigger mode is set to Auto, and the Horizontal

Scale is 10 ms/div or slower, changing the vertical position does

not reset the value

NOTE. In Scan mode, ACQuire:NUMACq? always returns zero.

Acquisition

ACQuire:NUMACq?

<NR1>

ACQuire:NUMACq?

Might return 350, indicating that 350 acquisitions t ook place since

an ACQuire:STATE RUN command was executed.

ACQuire:NUMAVg

Sets the number of oscilloscope waveform acquisitions that make up

an averaged waveform. This command is equivalent to setting the

Averages option in the Acquire menu.

Acquisition

Group

Syntax

Returns

Examples
