Appendix B: Automatic Measurements Supported
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
B-11
Table B- 2: Supported measurements and their definition (Cont.)
Measurements Annotation descri ptions
Histogram
measurement
annotations
Wfm Ct None
Hts in Box None
Peak Hits 1 vertical or horizontal bar indicating the peak hits.
Median 1 vertical or horizontal bar indicating the median bin.
Max 1 vertical or horizontal bar indicating the max bin.
Min 1 vertical or horizontal bar indicating the min bin.
Pk-Pk 2 vertical or horizontal bars indicat ing the min and max bins.
Mean 1 vertical or hori z ontal bar indicat ing the mean bin.
Std Dev 3 vertical or hori z ontal bars indicating the mean and mean 1 standard deviation.
U+/--1 3 vertical or horizontal bars indicating the mean and mean 1 standard deviation.
U+/--2 3 vertical or horizontal bars indicating the mean and mean 2 standard deviation.
U+/--3 3 vertical or horizontal bars indicating the mean and mean 3 standard deviation.
