Portable Mainframe Removal and Installation Procedures
10
TLA7000 Series Mainframe Technical Reference Manual
DVD Drive
Complete the following steps to remove the DVD drive. Refer to Figure 23 on
page 43 for the detailed exploded view drawings. Installation procedures are the
reverse of the removal procedures.
1. Remove the instrument covers. (See Instrument Covers on page 6.)
2. Remove the front panel display. (See Front Panel Display on page 8.)
3. Disconnect the ribbon cable and the power cable from the DVD drive.
4. Remove the two screws securing the DVD drive to the chassis.
5. Slide the DVD drive out of the chassis.
6. Remove the four screws securing the DVD drive to bracket assembly.
7. Remove the two screws securing the DVD board and spacer to the DVD
drive.
NOTE. Tighten the two screws securing the DVD board and spacer board to the
DVD drive to 2. 0 in-lbs. Tighten the four screws securing the DVD drive to the
bracket assembly to 2.0 in-lbs.
Motherboard
Complete the following steps to remove the motherboard. Refer to Figure 24 on
page 45 for the detailed exploded view drawings. Installation procedures are the
reverse of the removal procedures.
1. Remove the instrument covers. (See Instrument Covers on page 6.)
2. Remove the top EMI cover. (Refer to Figure 22 on page 41.)
3. Remove the six screws securing the motherboard to the chassis.
4. Remove the four rear jack screws.
5. Disconnect and pull all cables clear of the motherboard. (Refer to Figure 6
on page 11.)
6. Pass the DVD ribbon cable through chassis to clear the motherboard.
7. Move the motherboard forward to clear the USB grounding bracket and then
lift board out.
