Benchtop Mainframe Removal and Installation Procedures
TLA7000 Series Mainframe Technical Reference Manual
31
6-32 Screws (17)
Connector
0J4
J22
J23
J29
J24
Power switch
connector
Figure 20: Removing the backplane
