Tektronix TLA7012 Technical Reference Manual

Benchtop Mainframe Removal and Installation Procedures
24
TLA7000 Series Mainframe Technical Reference Manual
Slide the card guides toward the rear of
the mainframe; allow the front of the
card guide to snap into place.
Gently pull the card guide
forward until it pops out of place.
Installing card guides
Removing card guides
Front
Rear
Figure 15: Removing the t op and bott om card guides
