Operating Basics
Action: The osc
illoscope displays the type o f action that will immediately
occur when you push an Action option button. For example, when the Help
Index is visible, and you p ush the Page Down option button, the oscilloscope
immediately displays the next page of index entries.
Radio: The oscilloscope uses a different button for each option. The
currently-selected option is highlighted. For example, the oscilloscope
displays various acquisition mode options when you push the Acquire Menu
button. To select an option, push the corresponding button.
Page Selection Circular List
Action Radio
Trigger Menu
(channel 1)
Help Acquire
Type
Edge
Coupling
DC
Page
Up
Sample
or or
Page
Down
Peak Det
ect
Trigger Menu
(channel 1)
Average
Type
Video
Coupling
AC
or or
Trigger Menu
(channel 1)
Type
Pulse
Coupling
Ground
20 TPS2000B Series Digital Oscilloscope User Manual
