Application Examples
Taking Automatic
Measurements
The oscillosco
pe can take automatic measurements of most displayed signals.
NOTE. If a question mark (?) appears in the Value readout, the signal is outside
the measurement range. Adjust the Vertical Scale knob of the appropriate c hannel
to decrease the sensitivity or change the Horizontal Scale setting.
To measure signal frequency, period, and peak-to-peak amplitude, rise time, and
positive width, follow these steps:
1. Push the Measure button to see the Measure Menu.
2. Push the top option button; the Measure 1 Menu appears.
3. Push Type ► Freq.
The Value readout displays the measurement and updates.
4. Push the
Back option button.
5. Push the second option button from the top; the Measure 2 Menu appears.
6. Push Type ► Period.
The Value readout displays the measurement and updates.
7. Push the Back option .
8. Push the middle option ; the Measure 3 Menu appears.
9. Push
Type ► Pk-Pk.
The Value readout displays the measurement and updates.
10. Push the Back option .
11. Push the second option from the bottom; the Measure 4 Menu appears.
12. Push Type ► Rise Time.
The Value readout displays the measurement and updates.
1
3.
P
ush the Back option .
14. Push the bottom option ; the Measure 5 Menu appears.
15. Push Type ► Pos Width.
The Value readout displays the measurement and updates.
16. Push the Back option .
TPS2000B Series Digital Oscilloscope User Manual 39
