DIGITAL RECEIVER
Vers. 001 Flat Sat Light
23
On/off switch General power switch
Display Shows: service no., time, messages (ON, BOOT, etc…)
CAM modules Two slots for CAM PCMCIA modules
LNB input F-type connector for satellite dish lead.
LNB output F-type connector for second receiver (e.g. an analogue receiver) to
make use of the same satellite dish connection.
Computer port
DB9 connector for computer link
VCR SCART socket for video recorder connection
TV SCART socket for TV connection
S-VHS Video output connector in S-VHS
Audio outputs Auxiliary audio output connectors. L & R connectors are available as is
a S/PDIF connector for PCM (Digital) format audio output
Antenna input Traditional VHF/UHF band antenna input connector
TV output
TV signal output connector for signals from traditional antenna mixed
with UHF band digital receiver signal. These connections should only
be used if the TV does not have a SCART connector or a base band
audio/video input.
IR_Remote Remote control IR sensor connector
DataPort DataPort connector for additional devices
12V Power
supply
12 Volt power connector.
Fuse Fuse 10 A
Motor Unit Connector where you must connect the cable coming from the external
unit motors
