Connecting to the power supply
Using the supplied lead, connect up to an electrical power source. The electrical power
supply specifications are:
Power Supply 12V DC ±20 %
Socket-available current, minimum 5 Ampere.
Electrical power supplies provided via adapters must comply with the above-indicated
minimum requisites.
Use of unsuitable power supply devices such as rectified but non-stabilized
adapters, battery chargers, AC adapters or switching battery chargers may cause
malfunctions or damage. In this case the warranty is null and void.
Additional connections
Connecting to a video recorder
Insert the SCART cable in the socket (4) of the receiver (labelled VCR). This allows you to
record the selected service on tape or play a VHS cassette.
Connecting to a monitor in S-VHS
If you are using a monitor or TV with a S-VHS input the receiver can be connected via the
socket (6) labelled S-VHS. This type of connector provides a CVS video signal (i.e. with
luminance and chrominance signals separated); for the audio signal it will be necessary to
use the relevant sockets (7).
Connecting a Home Theatre system
The receiver can receive an audio signal in S/PDIF (PCM) digital format via the RCA
socket in the audio zone (7). Using a RCA-RCA lead, the digital audio signal can be sent
to an amplifier or Home Theatre system: this raises the audio on the received service to
CD-level quality.
