CA60Plus control panel Installation manual 17
ADDRESS 22 ZONE 2 TYPE AND ATTRIBUTES
The programming is the same as for Address 21
DEFAULT : FOLLOW type with BYPASS and STAY attributes
ADDRESS 23 ZONE 3 TYPE AND ATTRIBUTES
The programming is the same as for Address 21
DEFAULT : INSTANT type with BYPASS and STAY attributes
ADDRESS 24 ZONE 4 TYPE AND ATTRIBUTES
The programming is the same as for Address 21
DEFAULT : INSTANT type with BYPASS and STAY attributes
ADDRESS 25 ZONE 5 TYPE AND ATTRIBUTES
The programming is the same as for Address 21
DEFAULT : PANIC type
ADDRESS 26 ZONE 6 TYPE AND ATTRIBUTES
The programming is the same as for Address 21.
DEFAULT : TAMPER type
ADDRESS 29 ENABLING AND DISABLING FOR INSTANT TYPE ZONES
Intrusion in any Instant type zone during exit time is allowed or disallowed at
this address. Enabling this working mode would reduce the probability for a
false alarm signal to be triggered off by mistake on behalf of the user.
INSTANT ENABLE NO Disallows intrusion in INSTANT type zones during exit type.
Light-emitting diodes 1 to 6 do not light up.
YES Allows intrusion in INSTANT type zones during exit type. Light-emitting
diodes 1 to 6 light up.
DEFAULT : NO
ADDRESS 27 NUMBER OF ACTIVATIONS PER ZONE FOR AUTO BYPASS
MODE
The number of activations in one arm mode, which have to be accomplished for
a zone with an assigned AUTO/BPS parameter, are entered at this address.
After reaching the indicated number of activations, the respective zone will be
automatically bypassed.
When disarmed and then again armed the respective zone will remain armed.
DEFAULT : 6
ADDRESS 28 NUMBER OF ACTIVATIONS IN ZONE 4 IN PULSE COUNT
MODE
The number of pulses for zone 4 in Pulse Count mode are entered at this address.
Values of between 0 and 9 pulses can be entered here. The 0 value blocks the
Pulse Count mode and the zone can then function with the regular time for
detecting activation.
The working algorithm for zone 4 in Pulse Count mode has been clarified in
Item 7 on page 8.
DEFAULT : 0
