20 CA60Plus control panel Installation manual
3. Programming the PGM and SIREN programmable outputs
ADDRESS 31 PGM1 PROGRAMMABLE OUTPUT
The events, which activate the programmable output, are programmed at this
address.
An arbitrary combination of events, which activate the programmable output, is
allowed. The output is activated upon the occurrence of any of the programmed
events and is restored when all programmed events are discarded.
Press a digital button, which corresponds, to a given parameter. The parameter
will have been selected when the light-emitting diode on the display with the
respective number lights up.
To switch from one parameter group over to another use the arrows.
FIRST GROUP PGM1 PARAMETERS
1 ALARM It is activated when Entry\Exit, Follow and Instant type zones are violated while
the system is in armed mode, or when the 24h Burglar type zone, irrespective of
the arm mode, is violated. Output is restored after a legal user code is entered
or following an interval of 1 min.
2 PANIC It is activated when the PANIC type zone is triggered or when PANIC is triggered
from the keyboard. Output is restored after a legal code is entered.
3 TAMPER It is activated when TAMPER is triggered off in any zone, when a TAMPER
type zone is triggered off or when TAMPER is triggered from the keyboard,
irrespective of the arm mode. It is restored after activation is discarded.
4 FIRE It is activated when a FIRE type zone is triggered. It is restored after a legal
code is entered.
5 FIRE RST It is activated for 4 sec. after a legal code is entered.
6 ОN/OFF It is activated by a command to arm. Output is restored after disarming.
SECOND GROUP PGM1 PARAMETERS
1 MEDICAL It is activated when a MEDICAL type zone is triggered. Output is restored
after all MEDICAL type zones are restored.
2 PS/Bypass It is activated right after a zone has been designated to be bypassed or when the
zone has been assigned a Stay and Instant type arming. Output is restored after
disarming.
3 AC LOSS It is activated when there is a loss of the 220 V mains supply. ! If a delay for
the indication of the mains supply loss has been set (at Address 47), the
output shall be activated 30 minutes after supply loss! Output is restored
after the mains supply is restored.
4 BAT LOW It is activated when the battery voltage falls below 11 V, in case of damage to
the battery (BATT) fuse or if the battery is missing. It is restored after the level
of battery charge reaches a value greater than 12.5 V.
5 FUSE/NO TEL It is activated when a fault occurs in any of the AUX or PGM fuses, and/or
when a fault occurs in telephone line. It passes into inactive state when the fuse
and telephone line is restored.
6 POL +/- This attribute helps select the active level of the output. When “-“ is set (the
light-emitting diode is not lit) the active level is 0 V. At “+” the active level at the
output is 12 V.
DEFAULT : ON/OFF, POL “+”
