CA60Plus control panel Installation manual 21
ADDRESS 32 PGM2 PROGRAMMABLE OUTPUT
The programming is the same as for Address 31
DEFAULT : ALARM, TAMPER, POL “+”
ADDRESS 33 PGM3 PROGRAMMABLE OUTPUT
The programming is the same as for Address 31
DEFAULT : AC LOSS, BAT LOW, FUSE/NO TEL, POL “+”
ADDRESS 34 PROGRAMMABLE SIREN OUTPUT
The SIREN output can be activated by six events. The active level of this
output is low (0 V) and cannot be programmed.
An arbitrary combination of events is allowed to activate this output. It is re-
stored after bell time expires, which can be programmed at Address 42, ex-
pires.
ALARM It is activated when Entry\Exit, Follow and Instant type zones are violated while
the system is in armed mode, or when the 24h Burglar type zone, irrespective of
the arm mode, is violated. The output becomes inactive when a legal user or
manager code is entered or after bell time expires.
TAMPER It is activated when TAMPER is triggered off in any zone or when a TAMPER
type zone is triggered, irrespective of whether the site is armed or not. In case
the event activating the siren output has not been selected, the keyboards shall
emit a sound signal when TAMPER is triggered off. Output becomes inactive
when a legal user or manager code are entered or after the bell time, assigned
at Address 42, expires.
PANIC It is activated when the PANIC type zone is triggered or when PANIC is triggered
from the keyboard. Output becomes inactive when a legal user code is entered
or after the bell time, assigned at Address 42, expires.
FIRE/ALW A sequence of impulses is activated (1 second on, 1 second off) where the
FIRE type zone is triggered. Output becomes inactive when a legal user code is
entered. This event always activates the SIREN output and cannot be
cancelled.
ON SQUAWK It is singly activated for 1 second at the command to arm.
OFF SQUAWK It is activated twice for 1 second in a 1 second interval upon a disarm command.
DEFAULT : ALARM, PANIC, TAMPER, FIRE/ALW
