CA60Plus control panel Installation manual 29
ADDRESS 74 NUMBER OF RINGS
NUMBER OF The symbols 0 to 9 are used.
RINGS Up/ down loading is disabled if 0 is entered.
It is recommended this parameter does not exceed the value of 7.
DEFAULT : 7
7. Programming Up/Down Load parameters
ADDRESS 71 PERSONAL COMPUTER IDENTIFICATION NUMBER FOR UP
/ DOWN LOADING
PC ID The PC ID number for up / down loading is configured at this address. Four
digits can be introduced. Valid are symbols 0 to 9.
DEFAULT : 1234
ADDRESS 73 CALL BACK OPTION
This address enables the CALL BACK option function. Every push of the
digital button alternatively changes enabled to disabled status.
The connection fails if an allowed Call Back function is enabled during an incoming
exchange request to up / down load from a PC. The control panel selects the
number specified at Address 70 and an up / down load procedure is initiated.
The display indication on the keypad is described below.
YES The Call Back function is enabled. Light-emitting diodes 1 to 6 are lit.
NO The Call Back function is disabled. Light-emitting diodes 1 to 6 are not lit.
DEFAULT : NO
ADDRESS 72 CONTROL PANEL IDENTIFICATION NUMBER
PANEL ID The control panel up/down loading ID number is entered at this address. Four
digits can be introduced. Valid are symbols 0 to 9.
DEFAULT : 1234
ADDRESS 70 TELEPHONE NUMBER FOR UP / DOWN LOAD
PROGRAMMING
Tel No for An up / down load PC telephone number can be set at this address. The indication
Up / Down Load is hexadecimal. The maximal length must not exceed 16 characters, including
those for the “pulse dialer” (ON and 0 buttons), “tone dialer” (ON and 1 buttons),
“pause” (ON and 2 buttons), “wait DIAL tone” (ON and 3 buttons) and “delete
telephone number” (ON and 5 buttons) symbols.
Tone signal dialing was assigned by default.
DEFAULT : No telephone number has been entered
