CA60Plus control panel Installation manual 43
Revision history
Revision 4.31
1. Added menu 48 - fire duration.
2. Added menu 49 - enable/disable audible TAMPER.
3. Changed menu 69 - second half - events for transmit by second phone.
4. Added menu 76 - communications attempts.
5. Added menu 93 - communicator test.
6. Added menu 97 - internal clock adjustement.
7. Possibility of FORCE arming for zone type KEYSWITCH.
8. Added sound signal ALLARM to keyboards.
9. Clear LOG files after hardware RESET.
Revision 4.33
1. In menu 61 and 64 - panel ID can be hexadecimal.
Revision 5.0
1. Added possibility to attach voice dialer.
2. Added menu 80 - record and playback of voice messages.
3. Added menu 81, 82, 83, 84 - four phone numbers for voice dialer.
4. Added menu 85 - message type transission for voice dialer.
Message Event Example message
1
Alarm or tamper from Zone1 “ Alarm from Zone 1” or “Alarm in Entrance
zone”
2
Alarm or tamper from Zone2 “alarm from Zone 2” or “Alarm in the corridor”
3
Alarm or tamper from Zone3 “Alarm from Zone 3” or “Alarm in the children
room”
4
Alarm or tamper from Zone4 “Alarm from Zone 4” or “Alarm in the dinning
room”
5
Alarm or tamper from Zone5 “Alarm from Zone 5” or “Alarm in the bedroom”
6
Alarm or tamper from Zone
6
“Alarm from Zone 6” or “ Cable interrupting in
the alarm system”
7
The control panel turn off
with Ambush code
“Duress code have been entered”
8
Personal message “Message for Mr. John Smith”
Message Event Example message
1 Alarm in the system “ Burglary alarm”
2 Panic alarm in the system “ Panic or Duress code have been entered”
3 Tamper alarm in the system “ Cable interrupting in the alarm system”
4 Fire alarm in the system “Fire”
5 Medical alarm in the system “ Medical alarm ”
6 AC loss “AC power supply interrupting”
7 Battery low “ Battery too low ”
8 Common message “Message for Mr. John Smith”
Supplement E Example vioce message
Table 1: Message by zones (in 85 addres entered 0)
Table 2: Message by events (in 85 addres entered 1)
