2. Zone programming
ADDRESS 21 ZONE 1 TYPE AND ATTRIBUTES
This address includes two submenus. The zone type is set in the first one and the zone
attributes are set in the second one. Switching over from one submenu to the other is
done with the help of the arrows.
ZONE 1 TYPE SUBMENU
Only one type can be selected for a given zone. Press the digital button, which corre-
sponds to the number of the desired type. The indication is hexadecimal and is shown
in the table.
0 UNUSED The zone is not being used No light-emitting diodes light up
1 Entry/Exit Entry/exit zone Light-emitting diode 6 lights up
2 FOLLOW Follow zone Light-emitting diode 5 lights up
3 INSTANT Instant alarm zone Light-emitting diodes 5 and 6 light up
4 24h Burglar 24-hour instant alarm zone Light-emitting diode 4 light up
5 FIRE 24-hour fire zone Light-emitting diodes 4 and 6 light up
6 PANIC 24-hour panic zone Light-emitting diodes 4 and 5 light up
7 TAMPER 24-hour tamper zone Light-emitting diodes 4, 5 and 6 lights up
8 MEDICAL 24-hour medical zone Light-emitting diode 3 light up
9 SWITCH 24-hour zone switch type Light-emitting diodes 3 and 6 lights up
ZONE 1 ATTRIBUTE SUBMENU
Any one zone can be assigned more than one attribute. Pressing a digital button with
the respective number will activate a given attribute. The light-emitting diode with the
number of the pressed digit will light up to indicate the selection. Pressing the same digit
again will inactivate it and the light-emitting diode with the number of the pressed digit
will go out. At the end of this procedure, the light-emitting diodes, which correspond to
the assigned attributes only, will remain lit.
1 AUTOBYPASS Authorization for automatic Bypassing the zone after reaching the number of
activations per armed mode as set in address 27.
2 BYPASS Authorization to Bypass a zone.
3STAY The zone is not going to be armed in the STAY mode.
4 FORCE The zone will be bypassed if active when a Force type arm command is set.
5 DOUBLE DOUBLE KNOCK type zone
6 CHIME CHIME mode
DEFAULT : Entry/Exit type with BYPASS and CHIME attributes
Table 1 shows the types of zones and their attributes.
ADDRESS 20 TYPE OF ZONE BALANCING
The type of zone balancing is selected at this address. Every consecutive pressing of a
digital button alternatively changes the type of balancing. Display indications are given
in the table.
ALARM One balancing resistor. Light-emitting diodes 1 to 6 light up.
DUAL Two balancing resistors. Light-emitting diodes 1 to 6 do not light up.
DEFAULT : ALARM
