26 CA60Plus control panel Installation manual
6. Communicator parameters
The parameters of the built-in digital communicator are programmed at this
group of addresses.
Delete the queue of events to be sent to Address 93 by single pressing the 0
button before configuring communicator parameters.
ADDRESS 62 ENTERING PROTOCOL 1 NUMBER FOR THE
COMMUNICATOR
PROTOCOL 1 Enter central station No. 1 protocol number from the attached table. Valid are
the symbols from 0 to 2, where:
[0] User protocol – dialer – transmits a melody sound signal upon occurrence of
an event listed on the bottom on page 26
[1] ADEMCO CONTACT ID – see table with codes in Supplement B
[2] SIA (Level 1) - see table with codes in Supplement B
DEFAULT : 1
ADDRESS 60 ENTERING TELEPHONE NUMBER 1 FOR THE
COMMUNICATOR
Tel No 1 A telephone number is assigned for communicating with central station - No. 1.
The indication is hexadecimal. The telephone number must not exceed 16
characters, including the “pulse dialer” (ON and 0 buttons), “tone dialer” (ON
and 1 buttons), “pause” (ON and 2 buttons), “wait DIAL tone” (ON and 3
buttons) and “delete telephone number” (ON and 5 buttons) symbols.
Dialing has been assigned a default tone signal
DEFAULT : there is no number entered
ADDRESS 61 ENTERING PANEL IDENTIFICATION NUMBER 1
PANEL ID 1 Identification number for central station No. 1. Four digits are entered. Valid
are symbols 0 to 9, A to F (SIA) and B to F (ADEMCO)
DEFAULT : 9999
ADDRESS 64 ENTERING PANEL IDENTIFICATION NUMBER 2
PANEL ID 2 Identification number for central station No. 2. Four digits are entered. Valid
are symbols 0 to 9, A to F (SIA) and B to F (ADEMCO)
DEFAULT : 9999
ADDRESS 63 ENTERING TELEPHONE NUMBER 2 FOR THE
COMMUNICATOR
Tel No 2 A telephone number is assigned for communicating with central station No. 2.
The indication is hexadecimal. The telephone number must not exceed 16
characters, including the “pulse dialer” (ON and 0 buttons), “tone dialer” (ON
and 1 buttons), “pause” (ON and 2 buttons), “wait DIAL tone” (ON and 3
buttons) and “delete telephone number” (ON and 5 buttons) symbols.
Dialing has been assigned a default tone signal.
DEFAULT : there is no number entered
