CA60Plus control panel Installation manual 25
ADDRESS 57 TECHNICAL TROUBLE INDICATION MASK
The mask for sound indication from the keyboard in Technical Trouble mode is
assigned at this address.
The mask for sound indication from the keyboard in Technical Trouble mode is
assigned at this address.
Only those light-emitting diodes whose numbers correspond to technical prob-
lems for which sound indications are available will light up on the display at the
end of the procedure.
1 AC LOST Loss of 220 V mains supply.
2 BATT LOW Drop in battery charge, no battery or burnt out F1 battery fuse.
3 FUSE BLOWN Burnt out PGM fuse.
4 NO TEL LINE Loss of telephone line.
5 COMM ERROR Central station communication failure.
6 TAMPER Activated TAMPER within the system.
DEFAULT : AC LOST, BATT LOW, FUSE BLOWN, NO TEL LINE, COMM ERROR, TAMPER
ADDRESS 56 ENABLED KEYBOARD BLOCKING IN CASE OF ACCESS
CODE ERROR
ENABLE NO Disables keyboard blocking in case of access code mistake.
KBD Light-emitting diodes 1 to 6 do not light up.
BLOCK YES Enables keyboard blocking for 30 sec. following the triple introduction in
sequence of a false code. Light-emitting diodes 1 to 6 light up.
DEFAULT : NO
