CA60Plus control panel Installation manual 27
ADDRESS 66 WAIT DIAL TONE
WAIT DIAL TONE NO Disable DIAL signal test.
Light-emitting diodes 1 to 6 do not light up.
YES Enable DIAL signal test
Light-emitting diodes 1 to 6 light up.
DEFAULT : YES
ADDRESS 68 TEST MESSAGE TRANSMITTING PERIOD
TEST PERIOD Duration of transmission of test message in days (DD) is entered. The indication
is hexadecimal. Two digits must be entered. When entering a period
shorter than 10 days the first digit must be 0.
DEFAULT : 01 day
ADDRESS 65 ENTERING PROTOCOL 2 NUMBER FOR THE
COMMUNICATOR
PROTOCOL2 Enter central station No. 2 protocol number from the attached table. Valid are
the symbols from 0 to 2, where:
[0] User protocol – dialer – transmits a melody sound signal upon occurrence of
an event listed on the bottom on page 2618020xxx
[1] ADEMCO CONTACT ID – see table with codes in Supplement B
[2] SIA (Level 1) - see table with codes in Supplement B
DEFAULT : 1
ADDRESS 67 SETTING TEST TIME FOR SENDING MESSAGE
TEST TIME Time of sending test message to central station is entered . Hours and minutes
are entered (HH:MM). The indication is hexadecimal.
DEFAULT : 00:05 hours
ADDRESS 69 TYPES OF MESSAGE TRANSMITTED FROM THE DIGITAL
COMMUNICATOR *
The messages from both telephone numbers to the telephone monitoring central station, as well as the
report algorithm, are programmed at this address. The following report options can be set:
1. Message report from at least one of the two telephone numbers – Alternative report.
2. Independent message report to both telephone numbers –Split report.
3. Message report from one telephone number, which is also duplicated at the second –Both report.
The address consists of two identical submenus, structured as shown below. The first submenu is for
programming the streams of messages to the first telephone number, entered at address 60. The second
submenu is for programming the streams of messages to the second telephone number, entered respectively
at address 63. Switching over between the two submenus can be done with the help of the arrows.
Where message streams are marked only for the first telephone number, the report algorithm to be
used is Alternative report. There should be no marked message streams for the second telephone number.
Where the same message streams for both telephone numbers are marked, the report algorithm to be
used is Both report.
Where different message streams for both telephone numbers are marked, the report algorithm to be
used is Split report.
Both and Split reports can be jointly used.
The digital buttons 1 to 6 are used for programming. Pressing them each time will alternatively
change the status of the respective message type – report (LED lights up) or no report (LED does not light
