28 CA60Plus control panel Installation manual
* User protocol transmitted messages are ALARM, FIRE, PANIC, TAMPER, MEDICAL and
manually transmitted TEST signal. These messages are not programmable and are transmitted by
one and the same sound signal in the telephone line.
up). At the end of the procedure only those LEDs, which correspond to the designated for report mes-
sages, should remain lit up on the display.
1 ALARM ALARM and TAMPER type messages are transmitted.
2 PANIC PANIC type messages or entered assault code are transmitted.
3 FIRE FIRE and TAMPER type messages are transmitted.
4 ON/OFF+BPS BYPASS, ON/OFF type messages and engineer programming input are
transmitted.
5 MEDICAL MEDICAL type messages are transmitted.
6 TROUBLE TROUBLE and TEST type messages are transmitted.
DEFAULT : 1, 2, 3, 4, 5, 6 for the first telephone number. There are no marked streams for the second telephone
number.
