40 CA60Plus control panel Installation manual
Supplement C Additional information
Table of protocol Contact ID transmitted codes from CA60Plus
Code
100 Medical alarm Medical alarm
110 Fire alarm Fire alarm
120 Panic alarm Panic alarm
121 Duress code Code introduced under duress
130 Burglary alarm Alarm
137 Tamper alarm Tamper alarm
300 System trouble Trouble in the system
301 AC Loss No 220 V power supply
305 System RESET System parameters default reset
311 Battery missing No battery
351 Teleco Fail Telephone line failure
354 Failure to communicate Communication error
401 Open/Close by user Arming/Disarming by user
407 Remote Arm/Disarm Remote Arming/Disarming
408 Quick arm Quick arming (no code)
409 Keyswitch Open/Close Arming/Disarming from key-switch
571 Fire bypass Bypassing a FIRE type zone
572 24 h zone bypass Bypassing a 24 h Burglary type zone
573 Burglary bypass Bypassing an Entry/Exit, Follow or Instant type zone
601 Manual TEST report Manual TEST signal
602 Periodic TEST report Periodic TEST signal
627 Program mode entry Engineer programming mode entry
628 Program mode exit Engineer programming mode exit
Meaning
Default code passwords:
Manager code - 0000
User code 1 - 1111 - all rights
User code 2 - **** - all rights
User code 3 - **** - all rights
User code 4 - **** - all rights
User code 5 - **** - all rights
User code 6 - **** - all rights
User code 7 - **** - all rights
User code 8 - **** - all rights
User code 9 - **** - all rights
User code 10 - **** - all rights
User code 11 - **** - all rights
User code 12 - **** - all rights
User code 13 - **** - all rights
User code 14 - **** - all rights
User code 15 - **** - all rights
User code 16 - **** - all rights
Engineer code - 7777
**** - no code combination
Hexadecimal table
Key:
⊗ ⊗
⊗ ⊗
⊗ - lights O - not light.
The expression “ON and 1” means pressing the “ON” and “1” buttons in succession.
Value Status LED3..6 Keys
LED 3 LED 4 LED 5 LED 6 C ombi n ati on
0
ΟΟΟΟ
0
1
ΟΟΟ⊗
1
2
ΟΟ⊗Ο
2
3
ΟΟ⊗⊗
3
4
Ο⊗ΟΟ
4
5
Ο⊗Ο⊗
5
6
Ο⊗⊗Ο
6
7
Ο⊗⊗⊗
7
8
⊗ΟΟΟ
8
9
⊗ΟΟ⊗
9
A
⊗Ο⊗Ο
ON and 0
B
⊗Ο⊗⊗
ON and 1
C
⊗⊗ΟΟ
ON and 2
D
⊗⊗Ο⊗
ON and 3
E
⊗⊗⊗Ο
ON and 4
F
⊗⊗⊗⊗
ON and 5
