LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 10 of 73 2021-07-07
Not Subject to NDA
Product
2G Band
3G Band
4G Band
Region
LE910C1-ST
-
-
2, 4, 12, 66, 71
North America – T-Mobile
LE910C1-SV
-
-
4, 13
North America - Verizon
LE910C1-LA
2, 3, 5, 8
1, 2, 4, 5
1, 2, 3, 4, 5, 7, 28
Latin America
LE910C4-LA
2, 3, 5, 8
1, 2, 4, 5
1, 2, 3, 4, 5, 7, 28
Latin America
LE910C4-CN
3, 8
W: 1, 8
TDS: 34, 39
1, 3, 5, 8, 38, 39, 40, 41M China
LE910C1-SAX
-
-
2, 4/66, 12
North America - AT&T
LE910C1-SVX
-
-
4, 13
North America - Verizon
Table 2: Product Variants and their Frequency Bands
Refer to Chapter Reference Table of RF Bands Characteristics for detailed information
about frequencies and bands.
Target Market
LE910Cx-mPCIe can be used for wide variety of applications, where low power
consumption and low cost are required while achieving sufficient data rates:
• Mini PCIe applications
• Notebook PC
• M2M applications
Main Features
Function
Features
Modem
Multi-RAT cellular modem for voice and data communication
LTE FDD Catx data rates per the module variant used.
Carrier aggregation is not supported
GSM/GPRS/EDGE
WCDMA up to DC HSPA+, Rel.9
Regional variants with optimal choice of RF bands coverage of countries and MNOs
State-of-the-art GNSS solution with GPS/GLONASS/BeiDou/Galileo/QZSS receiver
Digital audio
subsystem
PCM/I2S digital audio interface
Up to 48 kHz sample rate, 16 bit words
USIM ports – dual
voltage
Class B and Class C support
Hot swap support
Clock rates up to 4 MHz
Application
processor
Application processor to run customer application code
32 bit ARM Cortex-A7 up to 1.3 GHz running the Linux operating system
Flash + DDR are large enough to allow for customer’s own software applications
