Telit Wireless Solutions LE910C1-AP Hw Design Guide

LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 51 of 73 2021-07-07
Not Subject to NDA
8. MECHANICAL DESIGN
Mechanical Dimensions
The LE910Cx-mPCIe overall dimensions are:
• Length: 50.95 mm
• Width: 30 mm
• Thickness 3.2 mm (Version with SIM holder : 4.62 mm)
• Weight
• With SIM holder: 10.3 grams
• Without SIM holder: 9.1 grams
8.1.1. Mechanical Drawing (with SIM Holder)
8.1.1.1. Top View
The figure below shows mechanical top view of the LE910Cx-mPCIe (with SIM holder)
