LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 16 of 73 2021-07-07
Not Subject to NDA
Pin
Signal
I/O
Function
Type
Comment
24
Reserved
-
25
Reserved
-
31
Reserved
-
33
Reserved
-
44
Reserved
-
46
Reserved
-
Table 7: Pin-out Information
Warning
: There are two different types of mPCIe modules; LE910Cx
mPCIe V1 and LE910Cx mPCIe V2. Two types of mPCIe modules have
different pinout on PCM signals but the rest of the pins are exactly the
same.
LE910Cx mPCIe V2 was developed to provide improved thermal
performance with the large solder resist opening area on the bottom
side of the module. For more details, refer to :
80576DSW10190A LE910Cx mPCIe HW Release notes.
mPCIe Pin-out
mPCIe V1
mPCIe V2
47
PCM_RX PCM_TX
49
PCM_TX PCM_RX
Warning
: Reserved pins must be left floating.
Pin-out for the Full Compatibility with PCI Express MiniCard
Specification.
Some pins of the LE910Cx mPCIe are different from the pin-out defined by the PCI
Express miniCard specification to support various functions of Telit.
But full compatibility with both PCI Express miniCard specification and Telit’s older xE910
mPCIe models was required. To meet this requirement, this model was developed.
