LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 11 of 73 2021-07-07
Not Subject to NDA
Function
Features
Interfaces
USB2.0 – USB port is typically used for:
Flashing of firmware and module configuration
Production testing
Accessing the Application Processor’s file system
AT command access
High-speed WWAN access to external host
Diagnostic monitoring and debugging
Communication between Java application environment and an external host CPU
NMEA data to an external host CPU
Peripheral Ports – SPI, I2C, UART
GPIOs
Antenna ports
Form factor
Full-Mini Card 52 pin, 50.95mm x 30mm x 1mm
Environment and
quality requirements
The entire module is designed and qualified by Telit for satisfying the environment and
quality requirements.
Single supply module
The module generates all its internal supply voltages.
RTC
No dedicated RTC supply, RTC is supplied by VBATT
Table 3: Functional Features
TX Output Power
Technology
Power (dBm)
2G LB
32.5
2G HB
29.5
3G/TD-SCDMA
23.5
4G FDD
22.5 @1RB
Table 4: Transmission Output Power
RX Sensitivity
Typical sensitivity levels are as follows:
Mode
Primary
Diversity
SIMO
3GPP
PCS 1900
-107.0
-
-
-102
DCS 1800
-106.5
-
-
-102
GSM 850
-108.0
-
-
-102
EGSM 900
-107.0
-
-
-102
WCDMA 2100 – B1
-108.5
-109.5
-111.0
-106.7
WCDMA 1900 – B2
-109.0
-110.0
-111.5
-104.7
