LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 63 of 73 2021-07-07
Moisture Sensitivity
The LE910Cx-mPCIe is a Moisture Sensitive Device level 3, in accordance with standard
IPC/JEDEC J-STD-020; it takes care of all related requirements for the use of this type of
components.
Moreover, the customer must take care of the following conditions:
a) Calculated shelf life in sealed bag: 12 months at <40°C and <90% relative humidity
(RH).
b) Environmental condition during the production: 30°C / 60% RH according to
IPC/JEDEC J-STD-033A paragraph 5.
c) The maximum time between the opening of the sealed bag and the reflow process
must be 168 hours if condition b) “IPC/JEDEC J-STD-033A paragraph 5.2” is
respected
d) Baking is required if conditions b) or c) are not respected
e) Baking is required if the humidity indicator inside the bag indicates 10% RH or
more
