74
Sidekick
®
Plus Test Set
K-TEST
• Distance measurement accuracy:
0.5% of DTS, ±0.5 Ω
• Maximum fault resistance: 20 MΩ
• Distance range: 0 to 20 km (0 to 65 kft)
• Fault1 / Fault2 > 2
• LoopR * 100 < Fault1 + Fault2
Tone
• Tracing tone generator (metallic and common
mode): 500 to 3500 Hz
• Reference tone: +14 to –20 dBm; 200 Hz to 20 kHz
TDR
• Range: 10 km (33 kft)
Ground Resistance Test
• Method: Fall of Potential
• Measurement range: 0 to 250 Ω
Impulse Noise (optional)
• Filters:
C (700 Hz to 3000 Hz)
E (1 kHz to 50 kHz)
F(5 kHz to 245 kHz)
G (20 kHz to 1100 kHz)
V(to 30 MHz) for VDSL-1 and VDSL-2 circuits
• Number of available thresholds: 3
• Threshold settings: -65 dBm to +5 dBm
• Blank time: 10 ms, 125 ms, 1000 ms
• Termination: 100 Ω, 135 Ω, 120 Ω
• Measurement time: 1 minute to 24 hours
• Standards: ANSI/IEEE 743
Environmental
• Operating temperature: –18 °C to 50 °C
(0 °F to 120 °F)
• Storage temperature: –18 °C to 50 °C
(0 °F to 120 °F)
• Operating humidity: BS EN 61010 “normal
conditions”. Up to 80% to 31 °C decreasing to 50%
at 40 °C. Condensation is not permitted.
• Environmental protection: This product is protected
to BS EN 60529 level IP20CW; do not use in wet
conditions (rain or high humidity).
Note: Supplied mains power charger is designed for
indoor use only. Use in other circumstances may place
the user at risk of electric shock.
