150Mbps Portable 3G Wireless Router User Guide
POWER: Mini USB power port for power adapter
connection or you can connect it to the PC’ USB port
with the included USB line.
LAN/WAN: The 100Mbps LAN/WAN Ethernet port, in
Wireless Router mode, it is used as a WAN access port
to connect the DSL MODEM, superior equipment, etc.
While in 3G Router, AP, and WISP mode, it is used as a
LAN port to connect the PC, Ethernet Switch.
USB: USB 2.0 port is for 3G USB Modem card
connection, such as TD-SCDMA, WCDMA2000, and
WCDMA, etc.
