Tenda Portable 3G Wireless Router - Prevent Network Attack

150Mbps Portable 3G Wireless Router User Guide
 Access Policy: Select one number from the drop-down
menu.
 Enable: Check to enable the access policy.
 Filtering mode: Select “Disable” to forbid the computer
at the filtered MAC address to access the Internet at a
specified time. Select “Enable” to permit the computer
at the filtered MAC address to access the Internet at a
specified time.
 Policy Name: Enter a name for the access policy
selected.
 MAC address: add the computer’s MAC address to the
MAC address field.
 Time: Select the time range of client filter rule.
 Date: select according to your needs.
 Apply: Select “Apply” to enable the settings.
For example:
If you want to forbid the LAN computer (MAC address is
00:22:15:55:2A:15) to access the Internet during 9 ：
00~18 ： 00 from Monday to Friday without restriction to
other time, you need to set the packet filtering list as the
above diagram.
11.4 Prevent Network Attack
72
