150Mbps Portable 3G Wireless Router User Guide
hosts’ corresponding ports to access the Internet at a
specified time.
 Start/End IP: Enter the starting/ending IP address.
 Port: Enter the controlled TCP/UDP protocol port; and it
can be a port range.
 Type: Select the protocol used by the controlled data
packets (TCP/UDP/Both).
 Time: Select the time range of client filter rule.
 Date: select according to your needs.
 Apply: Select “Apply” to enable the settings.
For example:
If you forbid the computer at the IP address of
192.168.0.100 to access the Internet from 9：00 to 18：00
everyday without restrictions to other computers in LAN, you
need to set the packet filtering list as the above diagram.
11.2 URL Filter
To better control the LAN computers’ access to the
websites; you can use URL filtering to permit or forbid their
access to certain websites at a specified time.
