150Mbps Portable 3G Wireless Router User Guide
WAN IP address for remote management.
NOTE:
1. If you want to login the device’s Web-based interface via
port 8080, you need to use the format of WAN IP address:
port (for example http ： //220.135.211.56:8080) to
implement remote login.
2. If your WAN IP address starts and ends with 0.0.0.0, it
means all hosts in WAN can implement remote Web
management. If you change the WAN IP address as
218.88.93.33-218.88.93.35, then only the computer with its
IP address at this IP address range (for example,
218.88.93.33, 218.88.93.34 and 218.88.93.35 )can
implement remote Web management
For example:
If you permit the WAN computer with the IP address of
218.88.93.33 to access the management interface via port
8080, then you need to fill in the parameters as the above
diagram.
11.6 WAN Ping
The ping test is to check the status of your Internet
connection. When this function is enabled, the router will not
respond to Ping request from WAN, but LAN computer can
ping pass.
