150Mbps Portable 3G Wireless Router User Guide
from 2~254)
 Subnet Mask: 255.255.255.0
For example:
 IP Address: 192.168.0.2
 Subnet Mask: 255.255.255.0
 DNS Server: Input the DNS server address provided
by your ISP. You can also use the Router as the DNS
proxy server. Click “OK” to save the configurations.
3.2 Connect with wireless network adapter.
If you switch to Wireless Router mode, you can only
access the Router’s web interface by using a wireless
network adapter. Then set the wireless connection as below.
3.2.1 ． Right click “My Network Places” on your computer
desktop and select “Properties”. As we can see from the
picture below, the wireless connection is disconnected.
3.2.2 ． Right click “Wireless Network Connection” and refer
to chapter 3.1.3 and 3.1.4 for IP address configuration.
3.2.3 ． Right click “Wireless Network Connection” and
select “View Available Wireless Networks”.
