Tenda Portable 3G Wireless Router - Chapter 9 Traffic Control; Traffic Control

150Mbps Portable 3G Wireless Router User Guide
Chapter 9 Traffic Control
9.1 Traffic Control
Traffic Control is for communication traffic limit in the LAN
and WAN. It can support limitation rules up to 20 entries and
simultaneously control maximum of 254 PCs' traffic. In
addition, IP address range configuration is supported.
 Traffic Control: To enable or disable the internal IP
traffic control. The default is disabled.
 Interface: Enter the actual uploading and downloading
bandwidth in WAN port.
 Service: To select the service type for traffic control,
such as HTTP service.
 IP Address ： The range of IP addresses, it can be a
single IP or IP range.
 UP/Down: To specify the traffic heading way for the
selected IP addresses: uploading or downloading.
64
