150Mbps Portable 3G Wireless Router User Guide
At present, the WPS supports up to 32 clients
PIN：If this option is enabled, you need to enter a PIN
code matching with the one in the wireless client.
WPS Summary: It displays the current status of Wi-Fi
protected setting, including authentication mode,
encryption type, default key and other information.
WPS Current Status ： “ Idle” means WPS is in idle
state. “Start MSC process” means the process has been
started and is waiting for being connected. Configured
means the negotiation between server and clients is
successful.
WPS Configured ： “ Yes” means WPS feature is
enabled and goes into effect. “No” means it doesn’t
takes effect. Usually when the AP-security has been
enabled, it displays “No”.
WPS SSID: It displays the main SSID set by WPS. WPS
only takes effect in main SSID
WPS Auth. Mode ： The authentication mode adopted
by WPS, usually it is WPA/WPA2-Personal mode.
WPS Encryption Type ： The encryption type used by
WPS, generally AES/TKIP.
WPS key：The effective key automatically generated by
AP.
AP PIN（KEY）：The PIN code used by default.
Reset OOB：Press this button, the WPS client will be in
idle state, and WPS indicator will turn off. AP will not
