Table 3-7 Show all Pin Assignment of Expansion Headers
Signal Name
FPGA Pin No.
Description
I/O Standard
GPIO_0
PIN_V10
GPIO Connection [0]
3.3-V LVTTL
GPIO_1
PIN_W10
GPIO Connection [1]
3.3-V LVTTL
GPIO_2
PIN_V9
GPIO Connection [2]
3.3-V LVTTL
GPIO_3
PIN_W9
GPIO Connection [3]
3.3-V LVTTL
GPIO_4
PIN_V8
GPIO Connection [4]
3.3-V LVTTL
GPIO_5
PIN_W8
GPIO Connection [5]
3.3-V LVTTL
GPIO_6
PIN_V7
GPIO Connection [6]
3.3-V LVTTL
GPIO_7
PIN_W7
GPIO Connection [7]
3.3-V LVTTL
GPIO_8
PIN_W6
GPIO Connection [8]
3.3-V LVTTL
GPIO_9
PIN_V5
GPIO Connection [9]
3.3-V LVTTL
GPIO_10
PIN_W5
GPIO Connection [10]
3.3-V LVTTL
GPIO_11
PIN_AA15
GPIO Connection [11]
3.3-V LVTTL
GPIO_12
PIN_AA14
GPIO Connection [12]
3.3-V LVTTL
GPIO_13
PIN_W13
GPIO Connection [13]
3.3-V LVTTL
GPIO_14
PIN_W12
GPIO Connection [14]
3.3-V LVTTL
GPIO_15
PIN_AB13
GPIO Connection [15]
3.3-V LVTTL
GPIO_16
PIN_AB12
GPIO Connection [16]
3.3-V LVTTL
GPIO_17
PIN_Y11
GPIO Connection [17]
3.3-V LVTTL
GPIO_18
PIN_AB11
GPIO Connection [18]
3.3-V LVTTL
GPIO_19
PIN_W11
GPIO Connection [19]
3.3-V LVTTL
GPIO_20
PIN_AB10
GPIO Connection [20]
3.3-V LVTTL
GPIO_21
PIN_AA10
GPIO Connection [21]
3.3-V LVTTL
GPIO_22
PIN_AA9
GPIO Connection [22]
3.3-V LVTTL
GPIO_23
PIN_Y8
GPIO Connection [23]
3.3-V LVTTL
GPIO_24
PIN_AA8
GPIO Connection [24]
3.3-V LVTTL
GPIO_25
PIN_Y7
GPIO Connection [25]
3.3-V LVTTL
GPIO_26
PIN_AA7
GPIO Connection [26]
3.3-V LVTTL
GPIO_27
PIN_Y6
GPIO Connection [27]
3.3-V LVTTL
GPIO_28
PIN_AA6
GPIO Connection [28]
3.3-V LVTTL
GPIO_29
PIN_Y5
GPIO Connection [29]
3.3-V LVTTL
GPIO_30
PIN_AA5
GPIO Connection [30]
3.3-V LVTTL
GPIO_31
PIN_Y4
GPIO Connection [31]
3.3-V LVTTL
GPIO_32
PIN_AB3
GPIO Connection [32]
3.3-V LVTTL
GPIO_33
PIN_Y3
GPIO Connection [33]
3.3-V LVTTL
GPIO_34
PIN_AB2
GPIO Connection [34]
3.3-V LVTTL
GPIO_35
PIN_AA2
GPIO Connection [35]
3.3-V LVTTL
