Demo batch file folder: \GSensor\demo_batch
The directory includes the following files:
• Batch file: test.bat
• FPGA configuration file: DE10_LITE_GSensor.sof
D
D
e
e
m
m
o
o
n
n
s
s
t
t
r
r
a
a
t
t
i
i
o
o
n
n
S
S
e
e
t
t
u
u
p
p
• Quartus II v16.0 must be pre-installed to the host PC.
• Connect the DE10-Lite board (J3) to the host PC with a USB cable and install the USB-Blaster
driver if necessary
• Execute the demo batch file “test.bat” from the directory \GSensor\demo_batch. This will load
the demo into the FPGA.
• Tilt the DE10-Lite board from side to side and observe the result on the LEDs.
