TM SERIES
1-1
TM Series Terex South Dakota, Inc. 472797 - 1/15
OPERATION GUIDELINES
SECTION 1
OPERATION GUIDELINES
NOMENCLATURE
Jib
Upper Controls
Platform
Upper Boom
Upper Boom
Extension Cylinders
Elbow Pin
Lower Boom
Lower Boom
Extension Rollers
Lower Boom
Lift Cylinder
Lower Controls
Outriggers
Strobe Light
Boom Tip
Upper Boom
Cylinder
Lower Boom
Extension
Cylinder
