TM SERIES
1-7
TM Series Terex South Dakota, Inc. 472797 - 1/15
OPERATION GUIDELINES
LIFT LOCK HANDLES
If a control lever at the upper controls operates a boom function, other than in the single stick, the control will
have a lift lock handle.
A spring-loaded lever on each boom function lever locks the levers in a neutral position and prevents
accidental actuation. A control lever placard indicates the direction to move the control lever to activate a
specific boom movement. To activate a boom movement the handle must be pulled ”up” and held, so the
control lever can operate the desired boom function. When the handle is released the spring pulls the handle
“down” to a neutral position and locks the control lever in that position.
Only the platform operator controls the Aerial Device during normal operation.
Never operate the Aerial Device from the ground control with someone in the
platform, except in an emergency situation.
All metal at boom tip is electrically connected.
Operator contact with ANY, live or grounded, line or object
while operator touches CONTROLS or BOOM TIP COMPONENTS
and boom tip contacts any other line or object can result in
Plastic or fiberglass covers offer limited electrical insulation.
Covers are NOT tested, certified, or maintained as insulating.
DO NOT Depend on machine covers for insulation
Comply with OSHA, ANSI, & NESC requirements
Cover all lines with insulated line hose or insulating blankets
Wear Personal Protective Equipment: Fall protection; Eye protection;
Maintain proper CLEARANCE to all lines and objects
Insulating: gloves, sleeves, and hard hat; & Special clothing
ELECTROCUTION HAZARD
DEATH OR SERIOUS INJURY
CONTROLS ARE NOT INSULATED OR ISOLATED
463602A
