Chapter 4 – Temperature Controller
Page 4-10 TestEquity 1007C Temperature Chamber
How to Hold/Resume a Running Profile
1. To Hold a running profile, press the Profile key
to enter the Profile Control menu.
• Then press ▲or ▼ to make your choice for Hold.
• Press ► to select Hold.
• The Main Page will appear with a profile status of
Holding. The Profile Indicator will be off.
Hold Profile:___________
Don’t Hold
► Hold
Terminate
Main Page_______________
► Profile 2 Holding
Step 2
█
SP1 23.0°C ▼
2. To Resume profile on hold, press the Profile key
to enter the Resume Profile menu.
• Then press ▲or ▼ to make your choice for
Resume.
• Press ► to select Resume.
Resume Profile:_________
Continue Holding
► Resume
Terminate
While a profile is on Hold, the current set point can be adjusted at the SP1 prompt on the Main
Page. When a profile is resumed during a Ramp step, the controller uses the Static Set Point from
the Main Page to calculate the rate of change needed to get to the set point at the end of the step.
When a profile is resumed in a soak step, the new set point value will be used as the soak value
for the time remaining in the step.
How to Terminate a Running/Holding Profile
1. Press the Profile key while the profile is running
to enter the Resume Control menu.
• Then press ▲or ▼ to make your choice for
Terminate.
• Press ► to select Terminate.
Hold Profile:___________
Don’t Hold
Hold
► Terminate
If you manually terminate a running profile, the profile ends with a set point of Off. This does
not turn off the chamber fan. The chamber temperature can reach +55°C just from heat generated
by the fan, and even higher if your test sample is energized. See Protecting an Energized Test
Sample in Chapter 5 for important information regarding energized test samples.
How to Delete or Re-Name a Profile
1. Go to the Profiles Page.
Move the cursor down the Main Page to
Go to Profiles, then press the ► key.
Main Page____________
► Go to Profiles ▲
Go to Setup
█
Go to Factory ▼
2. Choose Delete or Re-Name.
• Press ▲or ▼ to scroll through your choice.
• Press ► to select your choice.
• The controller will prompt you to select the profile
you want to delete or re-name.
Main>Profile_________
Edit Profile ▲
► Delete Profile
█
Re-Name Profile
